Dimensions : Ø 324 - h 4.3 mm
Tolerances : Dimensional: ±0.15mm
PCB thickness: ±10% - hole Ø: ±0.1mm - Fixing Fori per fissaggio con viti e/o pad termico biadesivo (opzionale)
Holes for screw fixing and/or biadhesive thermal pad (optional)
PCB FR4 1.6 mm
LED type SAMSUNG® 2835
LED q.ty 312
Beam angle 120°
RA/CRI Standard CRI>80,
Upon request CRI>90 CCT 2700K, 3000K, 4000K, 5000K
Step MacAdam (SDCM) 3 R9 CRI 80 CRI 90
