Waterproof Sign LED PCB Module , High CRI LED Module Panel Ring Shape
Description: Product Name:200(120)mm-5630*32pcs-DC-15WApplication:Ceiling/DecorativeSize:220(120)mmCRI:>80Flux:1800LMCCT:2700-6500kEfficiency(LM/W):120-140lm/WPF:>0.95Input Voltage:52VSDCM:<4 Steps (Erp)Connector:No ConnectorLED Chip:5630*32pcs
Application:
1. Ceiling lights 2. Advertisement light-box 3. Commercial luminaires 4. Channel lights 5. Troffer lamps 8. Panel lights 9. Down lights
|
Description
Ø Ideal for Down lights, Lowbay,Ceiling
Ø Module efficiency up to 140lm/W
Ø Colour tolerance 5 steps
Ø High colour rendering index CRI > 80(3000K,4000K),CRI>70(6000K)
Ø Push terminals for quick and simple wiring Simple installation (e.g. screws)
Technical Date
Ø Operating module at 300mA
| Order Code | -mA | VV |
CCT -K |
Flux -lm | CRI | Typ.Efficiency lm/W |
| RL-TOC88DA1008C-830 | 300 | 28-29.5 | 3000 | 1000 | 80 | 125 |
| RL-TOC88DA1008C-840 | 300 | 28-29.5 | 4000 | 1050 | 80 | 135 |
| RL-TOC88DA1008C-760 | 300 | 28-29.5 | 6000 | 1150 | 70 | 140 |
Ø Operating module at 350mA
| RL-TOC88DA1008C-830 | 350 | 29.5-31 | 3000 | 1150 | 80 | 120 |
| RL-TOC88DA1008C-840 | 350 | 29.5-31 | 4000 | 1250 | 80 | 130 |
| RL-TOC88DA1008C-760 | 350 | 29.5-31 | 6000 | 1350 | 70 | 135 |
Ø Operating module at 450mA
| RL-TOC88DA1008C-830 | 450 | 30-32 | 3000 | 1400 | 80 | 115 |
| RL-TOC88DA1008C-840 | 450 | 30-32 | 4000 | 1550 | 80 | 125 |
| RL-TOC88DA1008C-760 | 450 | 30-32 | 6000 | 1650 | 70 | 130 |
