Rugged Ridge LED Ring PCB Assembly Layout for Brake Light
The outermost ring of LEDs operate independently but share a common ground. The inner rings of LEDs possess 2 separate power inputs to allow for 2 levels of illumination. This board can be used as a completely integrated LED tail light, LED brake light and LED turn signal unit. The inner rings of LEDs can remain on with the tail lights and increase in brightness when the brakes are applied. The outermost ring of LEDs can be connected to the turn signal. All 60 LEDs on the board are domed surface mount components. Additional components included with the unit are surface mount resistors and diodes.
We make customized Vehicle LED Light PCB Module in your requirements:
Customized Diameter/size
Customized Circuit design
Customized LED quantity
Customized Power
Specified LED Chip ( SAMSUNG, CREE, or Other Brand)
Other special requirements on the functions
Bergquist Aluminum base copper-clad laminate have excellent flame retardant, high mechanical strength, dimensional stability etc. Especially it has very good heat sink, electromagnetic shielding and solder float.
It's widely used for the modifier and sparker on fire for motorcycle and mobile, power LED, sound box, power supply module and acoustics shielding system etc.
| One-Stop Service: | Tell us your need as clear as possible, usually we could answer all your questions and do all the rest things |
| Free Sample | We could make samples for free if your need is exactly clear |
| PCB Copy | Send us the sample, and we could make a copy which would save your cost |
| PCBA and enclosure design | Tell us your idea and requirements, our professional sales will understand you quickly and make your need clear on paper |
| PCB manufacturing | We have own machine&equipment to make the PCB within 1 week while the gerber file offered or confirmed. |
| Component sourcing & Purchasing | We have cooperation with many IC components and LED chip manufacturer which could control the cost |
| PCBA 100% test | Every unit will be tested and aged of your order |
