| Product Name: | Hot Sale 150w 3030 SMD LED UFO High Bay Light Module 60/90/120 Degree | Model No.: | HH-49-204-90-3030 |
|---|---|---|---|
| Beam Angle: | 60,90, 120 Degree | LENS Size: | Dia 200mm Height 7.48mm |
| Material: | Optical Grade PC | LED CHIP: | 3030 SMD LED, 140-150lm/w@ 150mA,6v |
| Tranmittance: | 91% | Application: | High Bay Light/Street Light |
| PCB Size: | 195mm Diameter, 1.5mm Thickness | Circuit: | 6 Series 34 Parallel |
Quick Detail:
Model No: HH-49-204-60-3030
Material: PC
Beam Angle : 60/90/120 degree
Lens size: Dia 200mm Height 7.48mm
PCB size: 195mm diameter, 1.5mm thickness
Match LED: 3030SMD LED
Small footprint, high light output
Features :
- This SKD 204 LED Array lens with PCB Module is best choice for High bay light 150w.
- Industry-leading thermal management utilizing technology
- Operating temperature range: from 35 Celsius degree to 70 Celsius degree.
- The LED retrofit kits contain no any mercury or lead.
- Does not produce UV rays that harm people’s eyes.
- Directional light means no light pollution, dark sky compliance.
- Optic lenses are available for projects that need smaller beam angles, like 90/120 degree.
Specifications:
1, Product Name | Hot sale 150w 3030 SMD LED UFO High Bay light module 60/90/120 degree |
2, Model No | HH-49-204-90-3030 |
3, Main parts | Round lens and PCB board with lens |
4, Lens Material | PC |
5, Lens size | Dia 200mm Height 7.48mm |
6, Transmittance | 91% |
7,LEDS | 3030 SMD LED, 140-150lm@ 150mA,6v |
8, Sample | 3-4 work day |
9, Delivery | 7-10 work days for 10000 sets |
10, Angle | 60 degree |
11, Quality guarantee | If you receive defective items, please email us a picture of the defective part. We will send you replacement without extra charger, or offer refund. |
12, Main market | Europe, South America,North America, Asia |
