Absolute Maximum Ratings (Ambient Temperature 25°C):
Properties Test conditions Value Unit
Power Dissipation (Red) PDiss R 24 mW
Power Dissipation (Green) PDiss G 16 mW
Power Dissipation (Blue) PDiss B 17 mW
Peak Forward Current IF Peak duty/ 10 @ 1 kHz 30 mA
Continuous Forward Current Red 10 mA
Continuous Forward Current Green 5 mA
Continuous Forward Current Blue 5 mA
Reverse Voltage VREV 1 μA 5 V
ESD Threshold/ Human Body Model VESD HBM 1000 V
Optical Properties:
Chip Technology AlInGaP + InGaN
Emitting Color Red & Green & Blue
Lens Type Diffused
General Information:
Operating Temperature -40 up to +85 °C
Storage Conditions (in original packaging) < 40 °C ; < 90 % RH
Storage Conditions (for single parts) -40 up to +85 °C
Moisture Sensitivity Level (MSL) 3
