FEATURES
High brightness cool white LED with maximum output above 1800lm
5000K, 5700K, and 6500K with 70CRI (typical) color points
Compact monolithic emitter ideal for directional lighting applications with high uniformity
Binned at +85°C
170lm/W typical efficacy at 700mA
5A DC maximum drive current
High thermal conductivity package - junction thermal resistance of only 2.5°C/W
120° wide viewing angle
8000V HBM ESD rating per MIL STD-883D
Electrically isolated thermal path
RoHS and REACH compliant
APPLICATIONS
Flashlight
Automotive accessory spotlights
Portable lighting accessories
Spotlight
Instrumentation
Work light
Battery and solar-powered applications
Bicycle light
SPECS
Illumination Color: Cool White
Wavelength/Color Temperature: 5000 K
Luminous Intensity: -
Luminous Flux/Radiant Flux: 300 lm
Color Rendering Index - CRI: 70
Viewing Angle: 120 deg
If - Forward Current: 700 mA
Vf - Forward Voltage: 2.75 V
Power Rating: 20 W
Length: 5 mm
Width: 5 mm
Height: 3.01 mm
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 80 C
Lens Color: Colorless
Lens Dimensions: 4.52 mm
Lens Shape: Dome
Lens Transparency: Water Clear
Series: SFT-40-W
Packaging: Reel
Packaging: Cut Tape
Packaging: MouseReel
Brand: Luminus Devices
Moisture Sensitive: Yes
