| Detailed Description | LED Lighting XLamp® XM-L White, Neutral 4500K 2.9V 700mA 125° 2020 (5050 Metric) |
|---|
Product Attributes
| TYPE | DESCRIPTION | SELECT ALL |
| Categories | Optoelectronics | |
|---|---|---|
| LED Lighting - White | ||
| Manufacturer | Cree Inc. | |
| Series | XLamp® XM-L | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Color | White, Neutral | |
| CCT (K) | 4500K | |
| Flux @ 85°C, Current - Test | - | |
| Flux @ 25°C, Current - Test | 250lm (240lm ~ 260lm) | |
| Current - Test | 700mA | |
| Voltage - Forward (Vf) (Typ) | 2.9V | |
| Lumens/Watt @ Current - Test | 123 lm/W | |
| CRI (Color Rendering Index) | 75 (Typ) | |
| Current - Max | 3A | |
| Viewing Angle | 125° | |
| Mounting Type | Surface Mount | |
| Package / Case | 2020 (5050 Metric) | |
| Supplier Device Package | SMD | |
| Size / Dimension | 0.197" L x 0.197" W (5.00mm x 5.00mm) | |
| Height - Seated (Max) | 0.124" (3.15mm) | |
| Thermal Resistance of Package | 2.5°C/W | |
| Base Part Number | XMLAWT |
